Taw qhia
● Cov Khoom Siv
ECR Iav Fiber + Resins + Sau Sau
Ins Cov taub
Orthophthalic (Ortho) | Ortho cob yog qhov ua rau xeb xeb. |
Isophthalic (ISO) | ISO cob yog qhov tsim nyog rau kev xeb thiab tshuaj lom neeg thiab muaj qhov hluav taws kub zoo nrog qhov muaj peev xwm tswj tau cov pa taws. |
Vinylester (VE) | VE tiv taus tshuaj, xws li cov kua qaub, ntsev, thiab lwm yam tshuaj lom. Hom roj ntoo no kuj tseem muaj hluav taws kub-resistant. |
Phenol ic | Phenol ic cob tiv taus cov tshuaj thiab yog cov hluav taws uas tiv taus thiab muab pa taws me heev. |
Thickness / Qhov Siab
13mm, 15mm, 20mm, 25mm, 30mm, 38mm, 40mm, 50mm, 60mm, 70mm
Size Mesh Qhov Loj
txheem ntxaij loj 38x38mm, 40x40mm, 50x50mm, 25x100mm thiab lwm yam
mini mesh loj 20x20 / 40x40mm, 19x19 / 38x38mm
micro mesh loj 13x13 / 40x40mm
● Vaj huam sib luag loj
1220x3660mm, 1000x3000mm, 1007x4007mm thiab lwm yam
 | Concave Nto (Meniscus nto) | Concave nto grating yog yig thiab tsis plam |
 | Du nto | Cov nplaim ntsej muag zoo tuaj yeem siv rau hauv kev lag luam khoom noj khoom haus thiab nqaij qaib lag luam uas yooj yim rau kev nyiam huv |
 | Gritted nto | Lub ntsej muag pob zom ua rau cov hniav muag tsis plam thiab muab txoj kev xav zoo nyob hauv qab. |
 | Sab saum toj Khoom Npog Ncaws | Feem ntau peb ntxiv 3mm-5mm thickness sab saum toj txheej npog ua kom cov grating li hnyav-ua vaj huam sib luag hnyav pem teb |
l Thov
|
|
|
Walkway Platform Grating | Kev Ntxuav Tsheb Pem Teb Txaus Tu | Stair Grating |
|
|
|
Kev Ua Liaj Ua Teb & Kev Lag Luam Qiv Nroj Hauv Tebchaws | Hniav Qab Nthab Roofing Grating | Tsob Ntoo Kev Ris Txiaj |
|
|
|
Laj Kab | Ciav khoob | Marine Kev Lag Luam Platform |
Vant Qhov zoo
Fiberglass pem teb ci ntsa iab yog qhov tsim nyog dua li cov ntaub ntawv ib txwm hauv daim ntawv thov.
Yooj Yim Txiav
Ua ntej nws tuaj yeem txiav sai thiab yooj yim, thiab yuav tsis hloov cov yam ntxwv ntawm cov khoom. koj tsuas yog yuav tsum tau txiav nws nrog lub kaum sab xis grinder, kev pom lossis txawm tias ib tus jigsaw nrog tus hniav zoo.
Sib Ntaus thiab Kev Lag Luam
Qhov thib ob ntawm cov fiberglass pem teb grating nrog lub ntom 4 lub sijhawm tsawg dua li hlau nws yog lub sib sib dua hauv kev ua kom yooj yim rau cov khoom siv rau ntawm qhov chaw, lub sijhawm nws txo tus nqi thauj khoom, tswj lub zog siab thiab qhov ua tau zoo thauj khoom.
Siv tshuaj tiv thaiv corrosion
fiberglass pem teb grating tiv taus tshuaj xeb yog li nws tuaj yeem siv rau yuav luag txhua qhov chaw ib puag ncig, nws tuaj yeem siv tau zoo hauv thaj chaw uas muaj lwm txoj hauv kev xaiv xws li hlau, ua vaj tse lossis ntoo yuav tsis sawv kev ua haujlwm xws li dej ntsev thiab cov chaw muaj tshuaj lom neeg.
Anti-Hluav Taws Kub & Anti-UV
fiberglass pem teb grating yog Anti UV, nws yog qhov tsis zoo yog li tuaj yeem siv kom muaj kev nyab xeeb nyob ib puag ncig hluav taws xob, nws yog tsim nrog hluav taws-plhaw hluav taws xob ntxiv raws li tus qauv, nws yog qhov cuam tshuam tiv taus yog li yuav tiv thaiv ib theem ntawm kev tsim txom thiab, nyob rau hnub no thiab hnub nyoog, ib qho ntawm nws cov pluses loj yog tias nws tsis muaj cov nqi seem yog li tawm ntawm lub radar ntawm cov tub sab.
Ua Nrog Ntsuas Kub
Nws tuaj yeem tiv taus qhov kub thiab txias ntawm thaj tsam ntawm -150 txog +150 degrees Fahrenheit yam tsis muaj kev cuam tshuam thiab, yog tias tshem tawm ntawm lub luag haujlwm, yuav rov qab mus rau nws daim ntawv qub ib lub nra tshem tawm.
● Txiav Tswv Yim
Peb tuaj yeem txiav nws tau zoo raws li qhov tshwj xeeb loj uas yuav tsum tau ua los ntawm cov neeg siv khoom.
Yog tias koj xav tau txiav los ntawm koj tus kheej, thov saib raws li cov lus qhia hauv qab no:
Muaj feem ntau ob txoj kev txiav, Ncaj kab txiav thiab Kab txiav txiav.Peb tuaj yeem siv ceramic disc lossis emery cutter rau kev txiav cov xwm txheej, txawm tias los ntawm ib qho zoo tib yam hacksaw hniav rau kev txiav. Hniav thickness yog 4-5 hli
Ceev faj ntawm kev txiav
1.Txawm nco ntsoov qhov loj me: txiav kom deb li ze nrog cov ntxaij thaiv kaw qhov loj me, nyob rau hauv no txoj kev thauj khoom zoo dua.
2.Fixed: grating yuav tsum tau tsau, kom tsis txhob txav thaum txiav
3.Safety: ua ntej txiav, cov neeg ua haujlwm yuav tsum hnav lub qhov muag tiv thaiv thiab lub ntsej muag thiab hnab looj tes thiab thoob plaws, qhov cua zoo, lub teeb ci xaiv sijhawm rau kev txiav plua plav, qhov loj me, yuav tsum them nyiaj rau hnav lub npog qhov ncauj qhov ntswg.
4.Grating shelving: feem ntau txiav rau hauv qab sab hauv txhawm rau kom txo cov khib nyiab thaum txiav
5.Txoj kev ncua: thov kos rau ntawm ntug ua ntej kev txiav. qhov dav sib txawv yog -6 hli ~ 0 hli; txoj kab uas hla sib txawv -9.5 hli ~ 0 hli;
6.Post-processing: tom qab txiav, qhov saum npoo xav tau coated nrog cob. Cov kev siv ntxig siv yog siab dua qib qib ntawm cov ntxaij hlau sib tsoo, thiab daim phiaj benzene uas nyob ib sab yog tsim los ntawm inter benzene resin tiv thaiv kom yaig ntawm cov iav fiber sab nraud.
7.Grinding: muaj lub kaum sab xis portable sib tsoo, kev sib tsoo tshuab, zoo tib yam sandpaper sib tsoo thiab foob.
8.Drilling: lub qhov saum toj 12 hli tuaj yeem tho nrog lub tshuab drilling, thiab lub qhov me me tuaj yeem nqa tau los ntawm tes.
● Peb Cov Kev Pab
Nantong Drayson Composite Material Co., ltd yog tsim nyob rau xyoo 2012.
Peb cov khoom tseem ceeb yog
FRP moulded grating
FRP pultruded grating
FRP pultruded yam ntxwv profiles
FRP qhov tes ua haujlwm & theem ntaiv
● Peb qhov zoo:
1. Ntau tshaj 25pcs cov pwm kev paub zoo & 5pcs ntawm pultrusion kab.
2.6000 square metres Hoobkas thiab 100 tus neeg ua haujlwm.
3.SGS, ISO tau ntawv pov thawj, thiab peb txhawb 3-kuaj ua ntej xa khoom raws li cov neeg siv khoom thov.
4.Txoj kev muag khoom muag nyiaj: 30 ntim cov lus nug ntxiv thov koj xav tiv tauj peb.
Cim npe nrov: fiberglass pem teb grating, Tuam Tshoj, tuam ntxhab, lwm tus neeg, Hoobkas, customized, nqe
