● Taw qhia

Cov khoom muaj pes tsawg leeg	ECR iav Fiber ntxiv Resins ntxiv rau ATH Filling
Resin hom	Ortho, ISO, VE, Phenolic
Xim	dub / dawb / liab / ntsuab / daj / xiav / grey thiab lwm yam.
Nto	Smooth, gritted, concave, sab saum toj khoom npog
Vaj Huam Sib Luag Loj	1220x3660mm, thiab lwm yam. thov download peb cov catalog kom paub meej ntxiv los yog xav tiv tauj peb rau cov lus qhia
Daim ntawv pov thawj	ISO9001: 2015, SGS ASTM E -84
Feature	Anti Hluav Taws / Corrosion / Slip / Ageing
Customized Vaj Huam Sib Luag Loj	Txhawb nqa
Cov ntsiab lus lag luam	EXW, FOB, CNF, CIF
Eco-Friendly	Yog lawm
Shipping Txoj Kev	Los ntawm hiav txwv / huab cua / nthuav qhia

antislip-gritted-frp-grating-for-walkway-fiberglass-FRP4

frp grating walkway 3

● Qhov Zoo


Tiv thaiv hluav taws Cov nplaim hluav taws kub hnyiab tau mus txog tus qauv ASTME -84. nws cov pa ntsuas ntsuas tuaj yeem ncav cuag ntau dua 35;	Siab zog Nws lub zog yog kaum lub sij hawm nruj PVC, lub zog lub zog yog ntau dua li txhuas, mus txog qib ntawm cov hlau zoo tib yam.	Kev ruaj ntseg FRP grating nyob rau hauv cov txheej txheem installation, yuav tsis muaj lub txim, tshwj xeeb tshaj yog haum rau kev siv nyob rau hauv ib qho chaw tawg;

Lub teeb nyhav FRP qhov kev faib ua feem yog nyob ib ncig ntawm 1.8g / cm3, txog 1/4 ntawm hlau, los yog 2/3 ntawm txhuas;	Anti-corrosion thiab anti-aging Nws yog stainless, tsis xeb, tsis muaj pwm, tsis rot, tsis muaj xim, resisting ntau gaseous, kua corrosivemedia	Ib qho yooj yim installation Lub installation tsis tas yuav nqa cov khoom siv, kev lag luam thiab yooj yim.

l Specification

Mesh Loj(mm)	Thickness(mm)	Bar Thickness (hli)	Standard Vaj Huam Sib Luag Loj (mm)
38x38	13	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	14	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	15	6.0/5.0	1220x3660,1220x4000,1220x2440
	20	6.0/5.0	1220x3660,1220x4000,1524x4010,997x3012
	25	6.5/5.0	1220x3660,1226x4010,1524x4000,1530x4010,1997x3012
	30	6.5/5.0	1220x3660,1220x4010,1524x4010,921x3055
	38	7.0/5.0	1220x3660,1220x4010,2100x4240,998x4010,1220x2440,921x3055,1530x4010
	50	9.5/7.5	1220x4010,1220x3666,1230x4010,1220x2440,921x3055
	60	10.5/8.5	1230x4010
	70	11.0/9.0	1230x4010
40x40	25	7.0/5.0	1007x3007,1007x4007,1247x4047,1527x4047
	30	7.0/5.0	1527x4047,1007x3007,1247x4047
	38	7.0/5.0	1527x4047,1247x4047,1007x3007,1007x4047
	40	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
50x50	15	6.0/5.0	1228x4020,1220x3660,1220x2440
	40	6.8/5.0	1787x4530,1225x4530
	25	7.0/6.0	1220x3660,1226x4020,1220x2440,915x3050
	50	8.0/6.0	1524x4000,1220x3660,1220x2440,1220x4000
83x83	38	7.0/5.0	1007x4007,1007x3007,1007x4255
83x83	40	7.0/5.0	1007x4007,1007x3007,1007x4255

l Adaim ntawv thovn


Lub Platform Grating	Tsheb Ntxuav Pem Teb Grating	Stair Grating

Farm & Breed Industry Floor Grating	Hniav Ceiling Roofing Grating	Tsob ntoo tiv thaiv Grating

laj kab Grating	Drain Grating	Marine Industry Platform

Nantong Drayson Composite Material Co., Ltd

cheeb tsam: Peb lub Hoobkas npog thaj tsam ntawm 20, 000 square metres thiab muaj cov qauv kev cob qhia uas tshaj 10, 000 square meters.
Sau npe peev: Nrog cov peev txheej sau npe pom ntawm 850,000 Dollars thiab qhov peev txheej tiag tiag ntawm 2,950,000 Dollars.
Daim ntawv pov thawj: Peb cov khoom tau ntawv pov thawj los ntawm ISO9001: 2008 International Standard Quality System, ASTME -84 thiab CE daim ntawv pov thawj.
