● Taw qhia

Cov khoom muaj pes tsawg leeg	ECR iav Fiber ntxiv Resins ntxiv rau ATH Filling
Resin hom	Ortho, ISO, VE, Phenolic
Xim	dub / dawb / liab / ntsuab / daj / xiav / grey thiab lwm yam.
Nto	Smooth, gritted, concave, sab saum toj khoom npog
Vaj Huam Sib Luag Loj	1220x3660mm, thiab lwm yam. thov download peb cov catalog kom paub meej ntxiv los yog xav tiv tauj peb rau cov lus qhia
Daim ntawv pov thawj	ISO9001: 2015, SGS ASTM E -84
Feature	Anti Hluav Taws / Corrosion / Slip / Ageing
Customized Vaj Huam Sib Luag Loj	Txhawb nqa
Cov ntsiab lus lag luam	EXW, FOB, CNF, CIF
Eco-Friendly	Yog lawm
Shipping Txoj Kev	Los ntawm hiav txwv / huab cua / nthuav qhia

● Qhov Zoo

Drayson Composite yog cov kws tshaj lij hauv FRP Floor Grating, peb cov khoom muaj zog, corrosion-resistant, plam resistant, saj zawg zog thiab hnav. Lawv tau yooj yim txiav nrog cov cuab yeej hluav taws xob txheem rau kev ua kom nrawm thiab txhim kho.

Nyhav Nyhav & HIGH SRENGTH

Nrog ib qho ntawm qhov siab tshaj plaws lub zog-rau-qhov hnyav piv ntawm cov khoom siv, FRP Pem Teb Grating muaj zog thiab ruaj khov, npaj rau xyoo ntawm kev siv tau zoo dua li cov hlau.

CORROSION RESISTANCE

Qhov tseem ceeb tshaj plaws ntawm FRP Floor Grating yog corrosion kuj. Nrog rau ntau yam kev hwm cov kab ke, nws yog qhov kev xaiv rau ntau qhov chaw corrosive. Nws yuav tsis rot, xeb los yog corrode, muab ntau xyoo ntawm kev siv nrog me me los yog tsis muaj txij nkawm. Tsis muaj scraping los yog painting yuav tsum tau.

TSIS TXAUS SIAB

Peb pom zoo kom cov Gritted Surface thiab Concave Surface grating kom ua tau raws li qhov yuav tsum tau ua kom tsis txhob plam. Kev sib tsoo thiab lub caij nplooj zeeg yog ib qho kim tshaj plaws thiab ntau hom kev sib tsoo, frp grating muaj kev nyab xeeb ntau dua hauv kev lag luam daim ntawv thov.

Yooj yim txiav thiab nruab

nws yog lub teeb yuag thiab yooj yim los tuav, yuav tsum tsis muaj kev nqa tshwj xeeb lossis cov cuab yeej teeb tsa.

lub grating tuaj yeem txiav tau yooj yim nrog cov cuab yeej siv hluav taws xob, siv masonry lossis pob zeb diamond embedded hniav. Peb pom zoo kom siv cov cab iav uas tau tsav lub voj voog, tab sis cov cuab yeej txheem siv tau rau feem ntau txiav.

hauv pem teb grating yog ib txwm hloov tau, muab ib qho yooj yim, tsis-skid nto uas yooj yim heev thiab muaj kev nyab xeeb rau sawv ntsug. Kev ua haujlwm hauv pem teb ergonomic txo qhov qaug zog thiab raug mob, thiab ua kom cov khoom tsim tau zoo, ua rau muaj kev ua haujlwm zoo dua qub.

Anti-Fire / Corrosion / UVLub teeb yuag / siab zogKev nyab xeeb / Yooj yim Installation

l Specification

Mesh Loj(mm)	Thickness(mm)	Bar Thickness (hli)	Standard Vaj Huam Sib Luag Loj (mm)
38x38	13	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	14	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055
	15	6.0/5.0	1220x3660,1220x4000,1220x2440
	20	6.0/5.0	1220x3660,1220x4000,1524x4010,997x3012
	25	6.5/5.0	1220x3660,1226x4010,1524x4000,1530x4010,1997x3012
	30	6.5/5.0	1220x3660,1220x4010,1524x4010,921x3055
	38	7.0/5.0	1220x3660,1220x4010,2100x4240,998x4010,1220x2440,921x3055,1530x4010
	50	9.5/7.5	1220x4010,1220x3666,1230x4010,1220x2440,921x3055
	60	10.5/8.5	1230x4010
	70	11.0/9.0	1230x4010
40x40	25	7.0/5.0	1007x3007,1007x4007,1247x4047,1527x4047
	30	7.0/5.0	1527x4047,1007x3007,1247x4047
	38	7.0/5.0	1527x4047,1247x4047,1007x3007,1007x4047
	40	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
50x50	15	6.0/5.0	1228x4020,1220x3660,1220x2440
	40	6.8/5.0	1787x4530,1225x4530
	25	7.0/6.0	1220x3660,1226x4020,1220x2440,915x3050
	50	8.0/6.0	1524x4000,1220x3660,1220x2440,1220x4000
83x83	38	7.0/5.0	1007x4007,1007x3007,1007x4255
83x83	40	7.0/5.0	1007x4007,1007x3007,1007x4255

l Adaim ntawv thovn


Lub Platform Grating	Tsheb Ntxuav Pem Teb Grating	Stair Grating

Farm & Breed Industry Floor Grating	Hniav Ceiling Roofing Grating	Tsob ntoo tiv thaiv Grating

laj kab Grating	Drain Grating	Marine Industry Platform

Nantong Drayson Composite Material Co., Ltd

cheeb tsam: Peb lub Hoobkas npog thaj tsam ntawm 20, 000 square metres thiab muaj cov qauv kev cob qhia uas tshaj 10, 000 square meters.
Sau npe peev: Nrog cov peev txheej sau npe pom ntawm 850,000 Dollars thiab qhov peev txheej tiag tiag ntawm 2,950,000 Dollars.
Daim ntawv pov thawj: Peb cov khoom tau ntawv pov thawj los ntawm ISO9001: 2008 International Standard Quality System, ASTME -84 thiab CE daim ntawv pov thawj.
