Fiberglass stair treads integral gritted top non-slip deg muab cov qib siab tshaj plaws ntawm kev ua haujlwm tsis zoo puas tau ntsuas rau qhov chaw taug kev, tshwj xeeb tshaj yog nyob rau hauv qhov chaw ntub thiab oily.Cov yam ntxwv ntawm corrosion ua rau nws tus kheej yog qhov kev xaiv zoo tshaj plaws rau harish ib puag ncig xws li tshuaj lom neeg thiab petrochemical cog qhov twg. xav tau ntau ntaiv lossis ntaiv.


Concave nto Ntuj crescent hli, anti skid.	Ntxim qab Nws tuaj yeem siv rau kev kho kom zoo nkauj xws li qhov rooj, muab faib, qab nthab, thiab lwm yam.	Gritted nto quarts ntawm qhov chaw, zoo dua los tiv thaiv skidding muaj nuj nqi

Mini mesh Mini mesh grating muaj ib feem plaubqhib cov qauv 38mm square mesh gratings, tuaj yeem tiv thaiv cov khoom me me li 13mm los ntawm kev poob.	Micro mesh Micro mesh grating muaj ib-cuaj qhib ntawm tus qauv 38mm squaremesh gratings, tuaj yeem tiv thaiv cov khoom me me li 8mm los ntawm kev poob.	Khoom npog Gritted phaj lossis checker phaj ntawm grating nto, tiv thaiv skid thiab tiv thaiv cov kua xau thiab roj volatilizin

Cov khoom siv

Peb tiv thaiv

Trench Srain Cover

Specifications

Mesh Loj (mm)	Thickness (hli)	Bar Thickness (hli)	Standard Vaj Huam Sib Luag Loj (mm)
38x38	13	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055,1264x4010
	14	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055,1264x4010
	15	6.0/5.0	1220x3660,1220x4000,1220x2440,921x3055,1264x4010
	20	6.0/5.0	1220x3660,1220x4000,1524x4010,997x3012
	25 (25.4 1")	6.5/5.0	1220x3660,1226x4010,1524x4000,1530x4010,1997x3012
	30	6.5/5.0	1220x3660,1220x4010,1524x4010,921x3055
	38 (38.1 1.5")	7.0/5.0	1220x3660,1220x4010,2100x4240,998x4010,1220x2440,921x3055,1530x4010,1530x3050,1000x4000,1226x3665
	50 (50.8 2")	9.5/7.5	1220x4010,1220x3666,1230x4010,1220x2440,921x3055
	60	10.5/8.5	1230x4010
	70	11.0/9.0	1230x4010
40x40	25	7.0/5.0	1007x3007,1007x4007,1247x4047,1527x4047
	30	7.0/5.0	1527x4047,1007x3007,1247x4047
	38	7.0/5.0	1527x4047,1247x4047,1007x3007,1007x4047
	40	7.0/5.0	1527x4047,1007x3007,1007x4047,1247x4047
50x50	15	6.0/5.0	1228x4020,1220x3660,1220x2440
	40	6.8/5.0	1787x4530,1225x4530
	25	7.0/6.0	1220x3660,1226x4020,1220x2440,915x3050
	50	8.0/6.0	1524x4000,1220x3660,1220x2440,1220x4000,915x3050,1532x4020
83x83	38	7.0/5.0	1007x4007,1007x3007,1007x4255
83x83	40	7.0/5.0	1007x4007,1007x3007,1007x4255

Khoom kom zoo dua


Anti-corrosion thiab anti-aging Nws yog stainless, tsis xeb, tsis muaj pwm, tsis rot, tsis muaj xim, muaj peev xwm ntawm resisting ntau gaseous, kua corrosive xov xwm;	Tiv thaiv hluav taws Cov nplaim hluav taws kub hnyiab tau mus txog tus qauv ASTME -84. nws cov pa ntsuas ntsuas tuaj yeem ncav cuag ntau dua 35;	Lub teeb nyhav FRP qhov kev faib ua feem yog nyob ib ncig ntawm 1.8g / cm3, txog 1/4 ntawm hlau, los yog 2/3 ntawm txhuas;

Siab zog Nws lub zog yog kaum lub sij hawm nruj PVC, lub zog lub zog yog ntau dua li txhuas, mus txog qib ntawm cov hlau zoo tib yam.	Ib qho yooj yim installation FRP grating daim ntawv thov txo tus qauv qhov hnyav, txo qhov hnyav ntawm cov qauv kev txhawb nqa, kev teeb tsa tsis tas yuav nqa cov khoom siv, kev lag luam thiab yooj yim.	Kev ruaj ntseg FRP grating nyob rau hauv cov txheej txheem installation, yuav tsis muaj lub txim, tshwj xeeb tshaj yog haum rau kev siv nyob rau hauv ib qho chaw tawg;

Packing & Delivery

Peb lub tuam txhab

Nantong Drayson Composite Material Co., Ltd

1. cheeb tsam: Peb lub Hoobkas npog thaj tsam ntawm 20, 000 square metres thiab muaj cov qauv kev cob qhia uas tshaj 10, 000 square meters.
2. Sau npe peev: Nrog cov peev txheej sau npe pom ntawm 850,000 Dollars thiab qhov peev txheej tiag tiag ntawm 2,950,000 Dollars.
3. Daim ntawv pov thawj: Peb cov khoom tau ntawv pov thawj los ntawm ISO9001: 2008 International Standard Quality System, ASTME -84 thiab CE daim ntawv pov thawj.

Peb Qhov Kev Pabcuam

Qauv
Cov qauv dawb: peb tuaj yeem muab cov qauv dawb rau koj kuaj.

Qhov zoo:
1.Low MOQ: Nws tuaj yeem ntsib koj lub lag luam zoo heev.
2.OEM Txais: Peb tuaj yeem tsim koj tus qauv tsim.
3. Kev Pabcuam Zoo: Peb kho cov neeg siv khoom ua phooj ywg.
4.Zoo Zoo: Peb muaj kev tswj xyuas nruj .Zoo lub koob npe nrov hauv khw.
5.Fast & Cheap Delivery: Peb muaj luv nqi loj los ntawm forwarder (Long Contract).

Tiv tauj peb

Lub npe	Rita Qin
Email	rita(at)ntdrs.com
whatsAPP	ntxiv rau 86-15950886070
Skype	yufan.qin
Wechat	qw 881108

Tuam Tshoj Mini Micro Mesh Frp Grating

Concave nto

Ntuj crescent hli, anti skid.

Ntxim qab

Nws tuaj yeem siv rau kev kho kom zoo nkauj xws li qhov rooj, muab faib, qab nthab, thiab lwm yam.

Gritted nto

quarts ntawm qhov chaw, zoo dua los tiv thaiv skidding muaj nuj nqi

Mini mesh

Mini mesh grating muaj ib feem plaubqhib cov qauv 38mm square mesh gratings, tuaj yeem tiv thaiv cov khoom me me li 13mm los ntawm kev poob.

Micro mesh

Micro mesh grating muaj ib-cuaj qhib ntawm tus qauv 38mm squaremesh gratings, tuaj yeem tiv thaiv cov khoom me me li 8mm los ntawm kev poob.

Khoom npog

Gritted phaj lossis checker phaj ntawm grating nto, tiv thaiv skid thiab tiv thaiv cov kua xau thiab roj volatilizin

Anti-corrosion thiab anti-aging

Nws yog stainless, tsis xeb, tsis muaj pwm, tsis rot, tsis muaj xim, muaj peev xwm ntawm resisting ntau gaseous, kua corrosive xov xwm;

Cov nplaim hluav taws kub hnyiab tau mus txog tus qauv ASTME -84. nws cov pa ntsuas ntsuas tuaj yeem ncav cuag ntau dua 35;

Lub teeb nyhav

FRP qhov kev faib ua feem yog nyob ib ncig ntawm 1.8g / cm3, txog 1/4 ntawm hlau, los yog 2/3 ntawm txhuas;

Siab zog

Nws lub zog yog kaum lub sij hawm nruj PVC, lub zog lub zog yog ntau dua li txhuas, mus txog qib ntawm cov hlau zoo tib yam.

Ib qho yooj yim installation

FRP grating daim ntawv thov txo tus qauv qhov hnyav, txo qhov hnyav ntawm cov qauv kev txhawb nqa, kev teeb tsa tsis tas yuav nqa cov khoom siv, kev lag luam thiab yooj yim.

Kev ruaj ntseg

FRP grating nyob rau hauv cov txheej txheem installation, yuav tsis muaj lub txim, tshwj xeeb tshaj yog haum rau kev siv nyob rau hauv ib qho chaw tawg;
